Hex Pin Pan Machine Screw

///Hex Pin Pan Machine Screw
  • HPPMS

Hex Pin Pan Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M12
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request

skype chat
Category: Tag:

▶ Hexagon recess screws with a central pin inside the six sided recess preventing removal with standard Allen keys
▶ Pan head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for medium torque application
▶ Matching security insert bits and L-Keys (Allen Keys) available

Size Driver Size Head Dia Head Height
M3 2.0mm 5.8mm 1.7mm
M4 2.5mm 7.8mm 2.4mm
M5 3.0mm 9.8mm 2.9mm
M6 4.0mm 11.8mm 3.5mm
M8 5.0mm 15.8mm 4.6mm
M10 6.0mm 19.81mm 5.8mm
M12 8.0mm 23.8mm 6.7mm
