Hex Pin Countersunk Machine Screw

///Hex Pin Countersunk Machine Screw
  • HPCMS

Hex Pin Countersunk Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M14
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request

skype chat
Category: Tag:

▶ Hexagon recess screws with a central pin inside the six sided recess preventing removal with standard Allen keys
▶ Countersunk head for a flush finish in a countersunk hole (screw length includes head)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for medium torque application
▶ Matching security insert bits and L-Keys (Allen Keys) available

Size Driver Size Head Dia Head Height
M3 2.0mm 5.7mm 1.7mm
M4 2.5mm 7.7mm 2.3mm
M5 3.0mm 9.8mm 2.8mm
M6 4.0mm 11.8mm 3.3mm
M8 5.0mm 15.1mm 5.0mm
M10 6.0mm 19.3mm 6.7mm
M12 8.0mm 23.2mm 7.4mm
