6-Lobe Pin Button Machine Screw

///6-Lobe Pin Button Machine Screw
  • 6LPBMS

6-Lobe Pin Button Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M14
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request

skype chat
Category: Tag:

▶ 6-Lobe Pin also known as: Star drive pin, Pin Torx,Torx-BO or resistorx
▶ 6-Lobe Pin screws with a central pin inside the six-lobe recess preventing removal with standard Torx tools
▶ Button head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for higher torque applications
▶ Matching security insert bits and L-Keys (Allen Keys) available

Size Driver Size Head Dia Head Height
M3 TX10 5.5mm 1.5mm
M4 TX20 7.4mm 2.1mm
M5 TX25 9.2mm 2.7mm
M6 TX30 10.4mm 3.2mm
M8 TX40 13.7mm 4.3mm
M10 TX45 17.0mm 5.6mm
