3 Hole Pan Machine Screw

///3 Hole Pan Machine Screw
  • 3HPMS

3 Hole Pan Machine Screw

Material:stainless steel & carbon steel
Security Level:
Size: M3-M6
Standard: DIN, ANSI, JIS, BS
Length:  4mm-80mm
Packing: Boxs or pallet or customer request

skype chat
Category: Tag:

▶ 3 Hole security screws is similar to 2 hole screw
▶ 3 Hole drilled into the head require a unique 3-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Pan head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available
▶ For customer request

Size Driver Size Head Dia Head Height
M3 Custom 5.8mm 1.7mm
M4 Custom 7.8mm 2.4mm
M5 Custom 9.8mm 2.9mm
M6 Custom 11.8mm 3.5mm
