2 Hole Pan Self Tapper

///2 Hole Pan Self Tapper
  • 2HPST

2 Hole Pan Self Tapper

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: ST2.9-ST6.3 #4-#14
▶Standard: DIN, ANSI, JIS, BS
▶ Length: 3/8″ -1.1/2″ 9.5mm-38mm
▶ Packing: Boxs or pallet or customer request
▶ can be used as wood screws

skype chat
Category: Tag:

▶ 2 Hole security screws, sometimes known as snake eye or pig nose
▶ Two holes drilled into the head require a unique 2-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Pan head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available
▶ can be used as wood screws

Size Driver Size Head Dia Head Height
#4 (2.9) TH3 5.4mm 1.6mm
#6 (3.5) TH4 6.7mm 2.0mm
#8(4.2) TH5 8.0mm 2.3mm
#10(4.8) TH6 9.2mm 2.7mm
#12(5.5) TH7 10.5mm 3.1mm
#14(6.3) TH8 12.2mm 3.5mm
