2 Hole Countersunk Machine Screw

///2 Hole Countersunk Machine Screw
  • 2HCMS

2 Hole Countersunk Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Length:  4mm-80mm
▶ Packing: Boxs or pallet or customer request

skype chat
Category: Tag:

▶ 2 Hole security screws, sometimes known as snake eye or pig nose
▶ Two holes drilled into the head require a unique 2-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Countersunk head for a flush finish in a countersunk hole (screw length includes head)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available

Size Driver Size Head Dia Head Height
M3 TH3 5.5mm 1.7mm
M4 TH5 7.3mm 2.2mm
M5 TH6 9.0mm 2.5mm
M6 TH8 10.7mm 3.0mm
