2 Hole Button Self Tapper

///2 Hole Button Self Tapper
  • 2HBST

2 Hole Button Self Tapper

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: ST2.9-ST6.3 #4-#14
▶Standard: DIN, ANSI, JIS, BS
▶ Length: 3/8″ -1.1/2″ 9.5mm-38mm
▶ Packing: Boxs or pallet or customer request

▶ can be used as wood screws

skype chat
Category: Tag:

▶ 2 Hole security screws, sometimes known as snake eye or pig nose
▶ Two holes drilled into the head require a unique 2-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Button head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available
▶ can be used as wood screws

Size Driver Size Head Dia Head Height
#4  (2.9) TX10 5.4mm 1.5mm
#6  (3.5) TX10 6.7mm 1.8mm
#8 (4.2) TX20 7.4mm 2.1mm
#10(4.8) TX25 9.3mm 2.6mm
#12(5.5) TX27 10.3mm 3.2mm
#14(6.3) TX30 11.0mm 3.4mm
