2 Hole Button Machine Screw

///2 Hole Button Machine Screw
  • 2HBMS

2 Hole Button Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Length:  4mm-80mm
▶ Packing: Boxs or pallet or customer request

skype chat
Category: Tag:

▶ 2 Hole security screws, sometimes known as snake eye or pig nose
▶ Two holes drilled into the head require a unique 2-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Pan head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available

Size Driver Size Head Dia Head Height
M3 TH3 5.5mm 1.5mm
M4 TH5 7.4mm 2.1mm
M5 TH6 9.1mm 2.7mm
M6 TH8 10.2mm 3.6mm
